SALE
Samurai 9,500 lbs Short Drum 12v Elec Winch w/Synth Rope | Warrior
$759.00
$736.00
(You save $23.00)
- SKU:
- 95DVA12-CAD
- Weight:
- 75.00 LBS
- SHIPPING:
- FREE to 48 States w/$150+Order
Samurai 9,500 lbs Short Drum 12v Elec Winch w/Synth Rope | Warrior
Description
- 456 mm wide drum for limited space installs
- Revolutionary Design External Brake
- 610 amp Silver Tip Contactor
- Silver Copper Motor with Copper Brush Holders
- Extensive Waterproof Sealing to IP68 Standard
The narrow drum version of the best selling 9500 Samurai. A total width of 456 mm ensures this is the perfect product for limited space!
The Short Drum winch is the preferred choice of the British Military on specialist vehicles currently serving in action.
Specifications
| SKU | PRNT-Samurai-9500-SD-CAD |
| Rated Line Pull (lbs) | 9500 |
| Motor Type | 12V:Input: 6.1hp/4.6Kw Output: 2.8hp/2.1kW |
| Gearing | 196:1 |
| Braking Action | External Brake |
| Clutch | Manual |
| Mounting Pattern | 5.94" x 4.5" (151 x 114.3 mm) |
| Cable Material | Steel or Synthetic |
| Drum Size - Dia x L | 2.48" x 4.72" |
| Dimensions (L x W x H) | 17.95'' x 6.30'' x 9.76'' |
| Product Weight (lbs) | 70.56 (32.0) |
Line Pull Spec
| Layer of Rope/Cable | Line Pull: lbs(kgs) | Rope on drum ft(m) |
|---|---|---|
| 1 | 9500 (4309) | 9.8 (3.0) |
| 2 | 7600 (3447) | 24.6 (7.5) |
| 3 | 6200 (2812) | 42.7 (13.0 |
| 4 | 5400 (2400) | 45.9 (14.0) |
| Line Pull lbs (kgs) | Line Speed 12v ft/min (m/min) | Amp Draw 12v |
|---|---|---|
| 0 | 36 (11.0) | 50 |
| 2000 (907) | 17.4 (5.3) | 120 |
| 3000 (1360) | 15.4 (4.7) | 150 |
| 6000 (2721) | 10.5 (3.2) | 260 |
| 8000 (3628) | 8.2 (2.5) | 300 |
| 9500 (4309) | 6.5 (2.0) | 355 |
